MKS Servo HBL575SL (0.07s/16.8kg/7.4V) Brushless Low Profile
MKS Servo is a manufacturer from Taiwan specializing in high quality and precise servo motors for RC model building, known for their performance and reliability in competitive environments. Located in the high-price segment, MKS Servo offers innovative servo technology that ensures high positioning accuracy and durability for demanding hobbyists and professionals. Their products are recognized in the RC community for top quality and outstanding performance.
High-voltage brushless motor (Brushless) Low-profile servo (Low-Profile)
- Ideal for 1/10 surface applications.
- Combines full metal gears, housing and amazing speed.
- The low dimensions are perfect for any vehicle that is tight on space.
- CNC machined metal housing design for exceptional cooling.
- HD 4096 resolution, 0.0008ms deadband.
- Superior holding torque, Japanese brushless motor.
- High speed, incredible efficiency and lower power consumption compared to comparable servos.
| SERVO SPECIFICATION | |
| Torque (kg-cm) | 10 (4.8V) / 13.3 (6.0V) / 16.8 (7.4V) |
| Torque (oz-in) | 138.9 (4.8V) / 184.7 (6.0V) / 233.3 (7.4V) |
| speed | 0.10s (4.8V) / 0.08s (6.0) / 0.07s (7.4V) |
| Stall Current (at locked load) | 1.9A (4.8V) / 2.4A (6.0V) / 2.9A (7.4V) |
| Working voltage | 4.8V ~ 8.4V DC Volts |
| Working Frequency | 1520μs / 333Hz |
| Deadband | 0.0008 ms (default) |
| Bearing | 2* Ball Bearings |
| Gear | Metal Alloy Gear |
| engine | Japanese-made brushless motor |
Specifications
- Brand
- MKS
- Tags
- 0.07s, 16.8kg, 7.4V, elektronik, low profile
- SKU
- HBL575SL
