SRT Servo BH922S 1/10 & 1/8 Onroad/Offroad HV (0.055s/8.4V/22kg) Brushless

SRT Servo BH922S 1/10 & 1/8 Onroad/Offroad HV (0.055s/8.4V/22kg) Brushless

KEY FEATURES

& Ideal for 1/10 on road and 1/8 off road scale applications
& Superior Holding Speed
& incredible efficiency and low power consumption
& Standard dimension make it perfect for vehicles that can benefit from a high quality servo
& CNC Machined aluminum case for exceptional cooling
& NMB dual main bearings
& SSR mode compatible
& 25T output shaft
& HD 4096 Resolution
& 2 μsec dead band
& 1-Year Limited Warranty

Item no	6.0V		7.4V		8.4V		Gear	Motor	Case	dimension (mm)	Weight (G)
	Speed: sec/60°	Torque: kg-cm/oz-in	Speed: sec/60°	Torque: kg-cm/oz-in	Speed: sec/60°	Torque: kg-cm/oz-in
BH922S	0.08	17.0/236.1	0.06	20.0/277.7	0.055	22.0/305.5	Titanium & Steel	Brushless	all-metal	40.0*20.0*38.0	70.0

Application :
1/10 1/8 Electric/ Car 1/10 1/8 Nitro/ Car  1/10 1/8 off-road
1/10 On-road  helicopter

PRODUCT SPECIFICATIONS

Type: Digital
Bearing: Dual
Motor Type: Brushless
Gear Type: Metal
Gear Material: Titanium & Steel
Control system: pulse width control
working frequency: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degrees
operating speed (6.0v): 0.08 sec/60 degrees at no load
operating speed (7.4v): 0.06 sec/60 degrees at no load
operating speed (8.4v): 0.055 sec/60 degrees at no load
stall torque (6.0v): 17.0kg.cm (236.1 oz/in)
stall torque (7.4v): 20.0kg.cm (277.7 oz/in)
stall torque (8.4v): 22.0kg.cm (305.5 oz/in)
potentiometer drive: direct drive
dimensions: 40x20x38.0 mm /1.57x0.79x1.49 in
weight: 70.0g (2.47 oz)
Connector wire length: jr 300 mm
